The JUSHA C270AG color medical diagnostic monitor with a resolution of 2 MP is designed for professional viewing and analysis of medical images. DICOM calibration, high brightness, accurate color reproduction and stable display characteristics make it a universal solution for various areas of medical imaging
• 14-bit LUT. Increased internal processing accuracy allows for better distinction of close grayscales and reduces DICOM display error, which is especially important for visualization of low-contrast areas of medical images
• DICOM calibration. DICOM Part 14 compliance and dynamic LUT ensure correct display of images at different levels of brightness, contrast and color temperature, increasing the accuracy and stability of diagnostic assessment of pathological changes
• Full Screen Uniformity technology - pixel-by-pixel calibration reduces the difference in brightness and color temperature (ensures uniformity) between individual areas of the screen, ensuring DICOM compliance across its entire area and reducing the risk of missed or erroneous diagnostic conclusions.
• High brightness. The maximum display brightness is 1000 cd/m², the maximum DICOM-calibrated - 600 cd/m². The combination of high brightness and contrast improves depth perception and detail of medical images
• Lightbox Mode - digital negatoscope mode. Allows you to temporarily increase the display brightness to the maximum level for viewing X-ray films without using a separate negatoscope.
• SmarTouch - a function for quickly increasing brightness. The function allows you to switch the display brightness between standard and maximum levels with a single press of a shortcut key, providing convenient viewing of medical images without constantly operating at maximum brightness
• Built-in front sensor. Provides continuous monitoring of the actual brightness directly on the display surface and transmits data to the calibration system for automatic correction of display parameters. It is provided to adjust the brightness of the black and white points, as well as the parameters of the DICOM ambient light curve according to viewing conditions and diagnostic needs, which allows you to maintain compliance with the DICOM standard during operation.
Get a modern medical monitor at a bargain price today!
WE OFFER:
5-YEAR WARRANTY
reliable service and maintenance 24/7
warranty and post-warranty support
free delivery throughout Ukraine and training on new equipment
possibility of payment in installments
demo room visit
training courses and conferences
For more information and a price offer for this model, fill out the feedback form on the website.
Ergonomics:
• 21.3″ IPS color LCD display
• Display area: 432 × 324 mm
• Pixel pitch: 0.27 × 0.27 mm
• Resolution: 1600 × 1200 pixels (2 MP)
• Aspect ratio: 4:3
• Brightness: 1000 cd/m² (max.) 600 cd/m² (DICOM-calibrated)
• Contrast ratio: 1400:1
• Viewing angle: horizontal/vertical 1780
• Display modes:
DICOM / Gamma 2.2 / Gamma 2.4 / CT / MRI / DSA (digital subtraction angiography) / DSI for specialized medical imaging
• Interfaces:
Video input signals: DP (x1) (Display Port 10 bit), DVI-D (8-bit) (x1)
USB interfaces: USB-B 2.0 (x1) Upstream, USB-A 2.0 (x2) Downstream
Built-in sensor system:
• Backlight sensor. Controls and stabilizes the display backlight
• Ambient light sensor. Compensates for the influence of ambient light
• Front sensor. Controls and stabilizes brightness and color
• Temperature sensor. Controls temperature changes to maintain stable display characteristics
• Presence sensor. Automatically switches the monitor to power saving mode when the operator is absent
Other features:
• Built-in quality assurance (QA) system. Provides control of the condition and stability of the display characteristics throughout the entire period of operation
• Accurate color reproduction. 30-bit color depth (10 bits per RGB channel) enables up to 1.07 billion colors for natural and detailed medical image reproduction
• Precise internal image processing. 14-bit LUT provides more accurate gradation processing and reduces DICOM calibration error, improving the distinction of close shades during diagnostic viewing
• Flexible display modes. DICOM, Gamma 2.2, Gamma 2.4, CT/MRI, DSA and DSI profiles are supported to adapt the display parameters to different types of medical images and clinical tasks
• Shark Gill Design — ergonomic case design. The shape of the ventilation elements of the case is inspired by shark gills and combines a modern appearance with a functional design of a medical monitor. The monitor design has been awarded an international award.
• Adjustable Multi-stance stand-bracket. Allows you to change the height and tilt angle of the display for a comfortable position during prolonged work with diagnostic images
